Simatic S7 1200 CPU 1212C DC DC DC

Simatic S7 1200 CPU 1212C DC DC DC Price in Bangladesh

Brand: Siemens

Model: 6ES7212-1AE40-0XB0

Country of Origin: China

Ask Price for order: Call/WhatsApp: +8801713722455



Category: Tags: , , , , , , ,

Description

The Simatic S7 1200 CPU 1212C DC DC DC, which is part number 6ES7212-1AE40-0XB0. The Simatic s7 1200 CPU 1212c dc dc dc 6ES7212 1AE40 0XB0 is the compact & Cost effective programmable Logic Controller (PLC). This S7 1200 CPU 1212C DC DC DC Programmable Logic controller (PLC) has Integrated Digital and analog function. This PLC 6ES7212 1AE40 0XB0 has 8 digital input 24V DC & 6 digital output 24V DC also 2 analog input points DC 0-10V. The power supply of 1212c dc dc dc is 24V DC. If you want to 6ES7212-1AE40-0XB0 price in BD, you can see our contact number below.

Specification of Simatic S7 1200 CPU 1212C DC DC DC

Part number 6ES7212-1AE40-0XB0
General information
Product type designation CPU 1212C DC/DC/DC
Firmware version V4.6
Engineering with
●   Programming package STEP 7 V18 or higher
Supply voltage
Rated value (DC)
●   24 V DC Yes
permissible range, lower limit (DC) 20.4 V
permissible range, upper limit (DC) 28.8 V
Reverse polarity protection Yes
Load voltage L+
●   Rated value (DC) 24 V
●   permissible range, lower limit (DC) 20.4 V
●   permissible range, upper limit (DC) 28.8 V
Input current
Current consumption (rated value) 400 mA; CPU only
Current consumption, max. 1 200 mA; CPU with all expansion modules
Inrush current, max. 12 A; at 28.8 V DC
I²t 0.5 A²·s
Output current
for backplane bus (5 V DC), max. 1 000 mA; Max. 5 V DC for SM and CM
Encoder supply
24 V encoder supply
●   24 V L+ minus 4 V DC min.
Power loss
Power loss, typ. 9 W
Memory
Work memory
●   integrated 100 kbyte
Load memory
●   integrated 2 Mbyte
●   Plug-in (SIMATIC Memory Card), max. with SIMATIC memory card
Backup
●   present Yes
●   maintenance-free Yes
●   without battery Yes
CPU processing times
for bit operations, typ. 0.08 µs; / instruction
Digital inputs
Number of digital inputs 8; Integrated
●   of which inputs usable for technological functions 6; HSC (High Speed Counting)
Source/sink input Yes
Number of simultaneously controllable inputs
all mounting positions
— up to 40 °C, max. 8
Input voltage
●   Rated value (DC) 24 V
●   for signal “0” 5 V DC at 1 mA
●   for signal “1” 15 V DC at 2.5 mA
Digital outputs
Number of digital outputs 6
●   of which high-speed outputs 4; 100 kHz Pulse Train Output
Limitation of inductive shutdown voltage to L+ (-48 V)
Switching capacity of the outputs
●   with resistive load, max. 0.5 A
●   on lamp load, max. 5 W
Output voltage
●   for signal “0”, max. 0.1 V; with 10 kOhm load
●   for signal “1”, min. 20 V
Analog inputs
Number of analog inputs 2
Input ranges
●   Voltage Yes
Input ranges (rated values), voltages
●   0 to +10 V Yes
— Input resistance (0 to 10 V) ≥100k ohms
Cable length
●   shielded, max. 100 m; twisted and shielded
Analog outputs
Number of analog outputs 0
Analog value generation for the inputs
Integration and conversion time/resolution per channel
●   Resolution with overrange (bit including sign), max. 10 bit
●   Integration time, parameterizable Yes
●   Conversion time (per channel)  625 µs
Encoder
Connectable encoders
●   2-wire sensor Yes
1. Interface
Interface type PROFINET
Isolated  Yes
automatic detection of transmission rate
Autonegotiation
Autocrossing
Interface types
●   RJ 45 (Ethernet) Yes
●   Number of ports 1
●   integrated switch No
Protocols
●   PROFINET IO Controller Yes
●   PROFINET IO Device Yes
●   SIMATIC communication Yes
●   Open IE communication Yes; Optionally also encrypted =
●   Web server Yes
●   Media redundancy No
PROFINET IO Controller
●   Transmission rate, max. 100 Mbit/s
Services
— PG/OP communication Yes; encryption with TLS V1.3 pre-selected
— Isochronous mode No
— IRT No
— PROFIenergy  No
— Prioritized startup Yes
— Number of IO devices with prioritized startup, max. 16
— Number of connectable IO Devices, max. 16
— Number of connectable IO Devices for RT, max. 16
— of which in line, max. 16
Protocols
Supports protocol for PROFINET IO Yes
PROFIsafe  No
PROFIBUS Yes; CM 1243-5 (master) or CM 1242-5 (slave) required
OPC UA Yes; OPC UA Server
AS-Interface Yes; CM 1243-2 required
Protocols (Ethernet)
●   TCP/IP Yes
●   DHCP No
●   SNMP Yes
●   DCP Yes
●   LLDP Yes
configuration / header
configuration / programming / header
Programming language
— LAD Yes
— FBD Yes
— SCL Yes
Know-how protection
●   User program protection/password protection Yes
●   Copy protection Yes
●   Block protection Yes
Access protection
●   protection of confidential configuration data Yes
●   Protection level: Write protection Yes
●   Protection level: Read/write protection Yes
●   Protection level: Complete protection Yes
programming / cycle time monitoring / header
●   adjustable Yes
Dimensions
Width 90 mm
Height 100 mm
Depth 75 mm
Weights
Weight, approx. 370 g

Conclusion

If you need to Simatic S7 1200 CPU 1212C DC DC DC Price in Bangladesh or if you need to 6ES7212 1AE40 0XB0 servicing or troubleshooting in BD, you can contact BAT Power Solution via Call/WahtsApp: +8801713s7 1200 cpu 1212c dc dc dc722455
