Siemens 6AV2 123 2DB03 0AX0

Description

Siemens 6AV2 123 2DB03 0AX0 is the SIMATIC Human Machine Interface (HMI) KTP400 Basic, The Basic Panel KTP400 Key/touch operation 4″ TFT display & 65536 colors has PROFINET interface communication and configurable from WinCC Basic V13/ STEP 7 Basic V13, contains open-source software.

The part number “Siemens 6AV2 123 2DB03 0AX0” refers to the Siemens SIMATIC HMI KTP400 Basic Panel. This is a compact HMI (Human-Machine Interface) designed for basic control and monitoring tasks in industrial environments.

Download datasheet

Others HMI



Key Features of the Siemens 6AV2 123 2DB03 0AX0 (KTP400 Basic):

+Series: SIMATIC HMI Basic Panels

+Model: KTP400 Basic

Display:

Size: 4-inch widescreen

Resolution: 480 x 272 pixels (WQVGA)

Type: TFT color display

Touchscreen: Resistive touch technology for reliable input.

Communication:

Interfaces: PROFINET (Ethernet) interface for communication with PLCs and other networked devices.

Ports: Typically includes one or more USB ports for connecting peripherals.

Functionality:

Buttons: Combination of touch interface and function keys for versatile control options.

Performance: Suitable for basic HMI applications with limited screen space requirements.

Software: Configured using Siemens’ TIA Portal software.

Mounting: Designed for panel mounting in control cabinets or operator panels.

Applications:

Industrial Automation: Used to interface with PLCs and other control systems, allowing operators to monitor and control various industrial processes.

Machinery Operation: Provides an intuitive user interface for operating and monitoring machinery in manufacturing, process control, and other industrial applications.

Data Visualization: Displays process data, alarms, and operational status, enabling real-time monitoring and decision-making.

Benefits:

User-Friendly Interface: The touch panel and function keys provide an intuitive and efficient user experience.

Compact Design: The small form factor makes it ideal for applications with limited space.

Integrated Communication: Easy integration with Siemens PLCs and other automation components through the PROFINET interface.



Specification of 6AV2123-2DB03-0AX0



Model or Part Number	Siemens 6AV2 123 2DB03 0AX0
General information
Product type designation	KTP400 Basic
Display
Design of display	TFT widescreen display, LED backlighting
Screen diagonal	4.3 in 95 mm
Display width	53.9 mm
Display height	65 536
Number of colors
Resolution (pixels)
●    Horizontal image resolution	480 pixel
●    Vertical image resolution	272 pixel
Backlighting
●    MTBF backlighting (at 25 °C)	20 000 h
●    Backlight dimmable	Yes
Control elements
Keyboard fonts
●    Function keys
— Number of function keys	4
— Number of function keys with LEDs	0
●    Keys with LED	No No
●    System keys	No
●    Numeric keyboard	Yes; Onscreen keyboard
●    alphanumeric keyboard	Yes; Onscreen keyboard
Touch operation
●    Design as touch screen	Yes; Analog-resistive
Installation type/mounting
Mounting position	vertical
Wall mounting/direct mounting	No
Mounting in portrait format possible	Yes
Mounting in landscape format possible	Yes
maximum permissible angle of inclination without external ventilation	35°
Supply voltage
Type of supply voltage	DC
Rated value (DC)	24 V
permissible range, lower limit (DC)	19.2 V
permissible range, upper limit (DC)	28.8 V
Input current
Current consumption (rated value)	125 mA
Starting current inrush I²t	0.2 A²·s
Power
Active power input, typ.	3 W
Processor
Processor type	ARM
Memory
Flash	Yes Yes
RAM	Yes
Memory available for user data	10 Mbyte
Type of output
Acoustics
●    Buzzer	Yes
●    Speaker	No
Time of day
Clock
●    Hardware clock (real-time)	Yes
●    Software clock	Yes
●    retentive	Yes; Back-up duration typically 6 weeks
●    synchronizable	Yes
Interfaces
Number of industrial Ethernet interfaces	1
Number of RS 485 interfaces	0
Number of RS 422 interfaces	0
Number of RS 232 interfaces	0
Number of USB interfaces	1; Up to 16 GB
Number of 20 mA interfaces (TTY)	0
Number of parallel interfaces	0
Number of other interfaces	0
Number of SD card slots	0
With software interfaces	No
Industrial Ethernet
●    Industrial Ethernet status LED	2
Protocols
PROFINET	Yes
Supports protocol for PROFINET IO	No
IRT	No
PROFIBUS	No
EtherNet/IP	Yes
MPI	No
Protocols (Ethernet)
●    TCP/IP	Yes
●    DHCP	Yes
●    SNMP	Yes
●    DCP	Yes
●    LLDP	Yes
WEB characteristics
●    HTTP	No
●    HTML	No
Redundancy mode
Media redundancy
— MRP	No
Further protocols
●    CAN	No
●    MODBUS	Yes; Modicon (MODBUS TCP/IP)
Interrupts/diagnostics/status information
Diagnoses
●    Diagnostic information readable	No
EMC
Emission of radio interference acc. to EN 55 011
●    Limit class A, for use in industrial areas	Yes
●    Limit class B, for use in residential areas	No
Degree and class of protection
IP (at the front)	IP65
IP (rear)	IP20
NEMA (front)
●    Enclosure Type 4 at the front	Yes
●    Enclosure Type 4x at the front	Yes
Standards, approvals, certificates
CE mark	Yes
cULus	Yes
RCM (formerly C-TICK)	Yes
KC approval	Yes
Use in hazardous areas
●    ATEX Zone 2	No
●    ATEX Zone 22	No
●    IECEx Zone 2	No
●    IECEx Zone 22	No
●    cULus Class I Zone 1	No
●    cULus Class I Zone 2, Division 2	No
●    FM Class I Division 2	No
Marine approval
●    Germanischer Lloyd (GL)	Yes
●    American Bureau of Shipping (ABS)	Yes
●    Bureau Veritas (BV)	Yes
●    Det Norske Veritas (DNV)	Yes
●    Lloyds Register of Shipping (LRS)	Yes
●    Nippon Kaiji Kyokai (Class NK)	Yes
●    Polski Rejestr Statkow (PRS)	No
●    Chinese Classification Society (CCS)	No
Ambient conditions
Suited for indoor use	Yes
Suited for outdoor use	No
Ambient temperature during operation
Operation (vertical installation)
— For vertical installation, min.	0 °C
— For vertical installation, max.	50 °C
Operation (max. tilt angle)
— At maximum tilt angle, min.	0 °C
— At maximum tilt angle, max.	40 °C
Operation (vertical installation, portrait format)
— For vertical installation, min.	0 °C
— For vertical installation, max.	40 °C
Operation (max. tilt angle, portrait format)
— At maximum tilt angle, min.	0 °C
— At maximum tilt angle, max.	35 °C
Ambient temperature during storage/transportation
●    min.	-20 °C
●    max.	60 °C
Relative humidity
●    Operation, max.	90 %; no condensation
Operating systems
proprietary	Yes
pre-installed operating system
●    Windows CE	No
configuration / header
Message indicator	Yes
Alarm system (incl. buffer and acknowledgment)	Yes
Process value display (output)	Yes
Process value default (input) possible	Yes
Recipe management	Yes
Configuration software
●    STEP 7 Basic (TIA Portal)	Yes; via integrated WinCC Basic (TIA Portal)
●    STEP 7 Professional (TIA Portal)	Yes; via integrated WinCC Basic (TIA Portal)
●    WinCC flexible Compact	No
●    WinCC flexible Standard	No
●    WinCC flexible Advanced	No
●    WinCC Basic (TIA Portal)	Yes
●    WinCC Comfort (TIA Portal)	Yes
●    WinCC Advanced (TIA Portal)	Yes
●    WinCC Professional (TIA Portal)	Yes
Languages
Online languages
●    Number of online/runtime languages	10
Project languages
●    Languages per project	32
Functionality under WinCC (TIA Portal)
Libraries	Yes
Applications/options
●   Web browser	Yes
●    SIMATIC WinCC Sm@rtServer	Yes; Available with WinCC (TIA Portal) V14 or higher
Number of Visual Basic Scripts	No
Task planner	Yes
●    time-controlled	No
●    task-controlled	Yes
Help system	Yes
●    Number of characters per info text	500
Message system
●    Number of alarm classes	32
●    Bit messages
— Number of bit messages	1 000
●    Analog messages
— Number of analog messages	25
●    S7 alarm number procedure	No
●    System messages HMI	Yes
●   System event, more (SIMATIC S7, SINUMERIK, SIMOTION, … )	Yes; System message buffer of the SIMATIC S7-1200 and S7-1500
●    Number of characters per message	80
●    Number of process values per message	8
●    Acknowledgment groups	Yes
●    Message indicator	Yes
●    Message buffer	Yes
— Number of entries	256
— Circulating buffer	Yes
— retentive	Yes
— maintenance-free	Yes
Recipe management
●    Number of recipes	50
●    Data records per recipe	100
●    Entries per data record	100
●    Size of internal recipe memory	256 kbyte No
●    Recipe memory expandable
Variables
●    Number of variables per device	800
●    Number of variables per screen	100
●    Limit values	Yes
●    Multiplexing	Yes
●    Structures	No
●    Arrays	Yes
Images
●    Number of configurable images	250
●    Permanent window/default	Yes
●    Global image	Yes
●   Pop-up images	No
●   Slide-in images	No
●   Image selection by PLC	Yes
●   Image number in the PLC	Yes
	Image objects
●   Number of objects per image	100
●   Text fields	Yes
●   I/O fields	Yes
●   Graphic I/O fields (graphics list)	Yes
●   Symbolic I/O fields (text list)	Yes
●   Date/time fields	Yes
●   Switches	Yes
●   Buttons	Yes
●   Graphic display	Yes
●   Icons	Yes
●   Geometric objects	Yes
Complex image objects
●   Number of complex objects per screen	10
●   Alarm view	Yes
●   Trend view	Yes
●   User view	Yes
●   Status/control	No
●   Sm@rtClient view	No
●   Recipe view	Yes
●   f(x) trend view	No
●   System diagnostics view	Yes; System message buffer of the SIMATIC S7-1200 and S7-1500
●   Media Player	No
●   HTML browser	Yes
●   PDF display	No
●   IP camera display	No
●   Bar graphs	Yes
●   Sliders	No
●   Pointer instruments	No
●   Analog/digital clock	No
	Lists
●   Number of text lists per project	300
●   Number of entries per text list	100
●   Number of graphics lists per project	100
●   Number of entries per graphics list	100
	Archiving
●   Number of archives per device	2; One message and one process value archive
●   Number of entries per archive	10 000
●   Message archive	Yes
●   Process value archive	Yes
●   Archiving methods
— Sequential archive	Yes
— Short-term archive	Yes
●   Memory location
— Memory card	No
— USB memory	Yes
— Ethernet	No
●   Data storage format
— CSV	No
— TXT	Yes
— RDB	No
	Security
●   Number of user groups	50
●   Number of user rights	32
●   Number of users	50
●   Password export/import	Yes
●   SIMATIC Logon	No
Character sets
●   Keyboard fonts
— US English	Yes
Transfer (upload/download)
●   MPI/PROFIBUS DP	No
●   USB	No
●   Ethernet	Yes
●   using external storage medium	Yes
Process coupling
●   S7-1200	Yes
●   S7-1500	Yes
●   S7-200	Yes
●   S7-300/400	Yes
●   LOGO!	Yes
●   WinAC	Yes
●   SINUMERIK	Yes; No access to NCK data
●   SIMOTION	Yes
●   Allen Bradley (EtherNet/IP)	Yes
●   Allen Bradley (DF1)	No
●   Mitsubishi (MC TCP/IP)	Yes
●   Mitsubishi (FX)	No
●   OMRON (FINS TCP)	No
●   OMRON (LINK/Multilink)	No
●   Modicon (Modbus TCP/IP)	Yes
●   Modicon (Modbus)	No
Service tools/configuration aids
●   Backup/Restore manually	Yes
●   Backup/Restore automatically	No
●   Simulation	Yes
●   Device switchover	Yes
Peripherals/Options
Printer	No
SIMATIC HMI MM memory card: Multi Media Card	No
SIMATIC HMI SD memory card: Secure Digital memory card	No
SIMATIC HMI CF memory card Compact Flash Card	No
USB memory	Yes
SIMATIC IPC USB Flashdrive (USB stick)	Yes
SIMATIC HMI USB stick	Yes
Mechanics/material
Enclosure material (front)
●   Plastic	Yes
●   Aluminum	No
●   Stainless steel	No
Dimensions
Width of the housing front	140 mm
Height of housing front	116 mm
Mounting cutout, width	124 mm
Mounting cutout, height	100 mm
Overall depth	34.9 mm
Weights
Weight (without packaging)	360 g
Weight (with packaging)	470 g
