Mitsubishi MELSEC FX2N 64MR 001

Description

The Mitsubishi MELSEC FX2N 64MR 001 is the most advanced series of PLC family is FX series. This compact offering accommodates eight special function modules for extremely fast program execution and provides maximum flexibility and control capabilities for all your factory automation applications. In addition to the features already listed, the FX2N also offers the following Mitsubishi PLC FX2N-64MR-001 Also all FX2N series PLCs are available in our BAT Power Solution stock.

Key Features Mitsubishi MELSEC FX2N 64MR 001

1. Type: CPU
2. I/O Points:
   • Digital Inputs: 32 points
   • Digital Outputs: 32 points
3. Voltage Rating:
   • Inputs: DC 24V
   • Outputs: DC 24V & 220V AC

others PLC

Specifications Mitsubishi MELSEC FX2N 64MR 001

• Digital Inputs:
  • Channels: 32 points
  • Input Voltage: DC 24V
  • Input Current: Approximately 3mA per point
• Digital Outputs:
  • Channels: 32 points
  • Output Voltage: DC 24V & 220V

Manufacturer: Mitsubishi Electric

Product No.: FX2N-64MR-001

Product type: Fx2n Series Programmable Controllers

PLC type: FX2N

Total number of I / O channels: 64

Number of Input: 32

Number of Output: 32

Unit type: MPU – main unit

Output type: Relay

Applications:

• Factory Automation: Ideal for controlling a variety of machines, conveyors, and automated systems requiring digital I/O signals.
• Process Control: Suitable for applications needing control over digital devices, sensors, and actuators.
• Building Automation: Used for controlling lighting, HVAC systems, and other building management functions.

Benefits:

• High Capacity: Offers 32 digital inputs and 32 digital outputs, providing ample I/O points for large-scale automation systems.
• Compact Design: Space-efficient design that fits comfortably in control panels with limited space.
• Reliability: Designed to withstand harsh industrial environments, ensuring durability and long-term performance.
• Ease of Installation: Features clear labeling and DIN rail mounting for quick and straightforward installation.

Installation and Configuration:

1. Mounting:
   • Install the FX2N-64MR-001 module on a DIN rail inside a control panel.
2. Wiring:
   • Connect the digital inputs and outputs to the corresponding terminals, following the wiring diagrams provided in the user manual.
3. Software Setup:
   • Utilize Mitsubishi’s GX Works2 or GX Works3 software for configuration:
     • Define the digital input and output points.
     • Set the input and output parameters, including input logic type and output control settings.
     • Integrate the module into your PLC program and establish the control logic.
4. Testing:
   • Download the configuration to the PLC.
   • Use the PLC’s diagnostic tools to monitor and verify the operation of the digital inputs and outputs.
   • Perform comprehensive testing to ensure all digital signals are accurately processed and controlled.

The FX2N-64MR-001 is a high-capacity digital I/O module designed for Mitsubishi FX series PLCs, offering 32 digital input and 32 digital output points. It is ideal for various industrial automation applications, providing reliable and efficient control of digital signals. Proper installation and configuration using Mitsubishi’s software tools will ensure the module performs optimally in your automation systems.
