Hitech HMI programming cable USB HITECH

Description

The Hitech HMI programming cable USB HITECH is used for connecting a computer to Hitech HMIs (Human-Machine Interfaces) for programming, downloading, and uploading project files. This cable provides a USB interface that is convenient for modern PCs, replacing the older serial cables used for communication with Hitech HMI devices. If you need to hmi hitech pws6600s s hitech hmi programming cable price in BD, USB-HITECH you can contact BAT Power Solution WhatsApp: +8801713722455

Hitech HMI programming cable USB HITECH Details

1. Cable Model:
   • USB-HITECH is specifically designed for Hitech HMIs.
   • Compatible with a variety of Hitech HMI models that utilize a DB9 (9-pin serial) communication port.
2. Connection Type:
   • The cable has a USB Type A connector for connecting to the computer.
   • The other end of the cable is equipped with a 9-pin D-sub (DB9) connector that plugs into the serial communication port on the HMI.
3. Use Case:
   • The USB-HITECH cable is used to download/upload HMI projects, configure settings, and update firmware.
   • It is compatible with ADP software (Automation Design Programming) used for Hitech HMIs.
4. Cable Length:
   • The cable length is typically 1.5 to 2 meters, providing adequate reach for programming and maintenance activities.
5. Driver Requirements:
   • This cable requires a USB-to-serial driver, which creates a virtual COM port on the computer to facilitate communication.
   • Drivers may be included with the cable, or they can be downloaded from the manufacturer’s support website.

Installation and Connection Instructions

1. Connect the Cable:
   • Plug the USB Type A connector into an available USB port on your computer.
   • Connect the 9-pin DB9 connector to the communication port on the Hitech HMI.
2. Driver Installation:
   • Upon connecting the USB cable to the computer for the first time, it may prompt you to install a driver.
   • Install the USB driver to set up the virtual COM port, which will be required to establish a proper connection with the HMI.
   • If the driver is not installed automatically, you can download it from the Hitech support website or from the resources provided with the cable.
3. Software Setup:
   • Open the ADP software on your computer. This software is used for programming Hitech HMIs.
   • In the software’s communication settings, select the correct COM port that the USB-HITECH cable has been assigned (this can be found in Device Manager).
4. Programming and Configuration:
   • Once the cable is connected and recognized, use the ADP software to create, modify, and download projects to the Hitech HMI.
   • You can also perform real-time monitoring and testing through this connection.

The USB-HITECH programming cable is an essential tool for connecting a Hitech HMI to a computer via a USB port. It uses a USB to DB9 (9-pin serial) connection and requires a driver to create a virtual COM port for proper communication. The cable works with ADP software, allowing users to easily program and configure the Hitech HMI. Others Cable
