E3JK DR12 C 2m Omron photoelectric sensor
Original price was: 6,000.00৳ .4,000.00৳ Current price is: 4,000.00৳ .
Description
The E3JK DR12 C 2m Omron photoelectric sensor of OMRON Corporation, A photoelectric sensor detects the photo-optical workpiece. OMRON offers a variety of sensors, including diffuse-reflective, through-beam, retro-reflective, and distance-settable sensors, as well as sensors with built-in or separate amplifiers and fiber units.
Specification of E3JK DR12 C 2m Omron photoelectric sensor
| Brand | OMRON |
| Model | E3JK-DR12-C |
| Type of product | Photoelectric Sensor |
| Length | 2M |
| Made In | China |
| Sensing method | Diffuse-reflective |
| Sensing distance | White paper 100 x 100 mm: 300 mm |
| Differential distance | 20% max. of sensing distance |
| Light source | Red LED (624 nm) |
| Power supply voltage | 24 to 240 VAC±10% 50/60 Hz |
| 24 to 240 VDC±10% ripple (p-p) 10% max. | |
| Power consumption | 2 W max. |
| Control output | Relay output (SPDT) |
| 250 VAC 3 A (cosφ= 1) max. | |
| 5 VDC 10 mA min. | |
| Life expectancy (relay output) | Electrical: 100 thousand times or more (switching frequency 1800 times/hour) |
| Mechanical: 50 million times or more (switching frequency 18000 times/hour) | |
| Operation mode | Light-ON & Dark-ON |
| Response time | 20 ms maximum |
| Sensitivity setting | Single-turn adjustment |
| Ambient illuminance | Incandescent lamp: 3,000 lx |
| Sunlight: 11,000 lx | |
| Ambient temperature range (Operating) | -25 to 55 ℃ (with no freezing or condensation) |
| Ambient temperature range (Storage) | -40 to 70 ℃ (with no freezing or condensation) |
| Ambient humidity range (Operating) | 35 to 85 % (with no condensation) |
| Ambient humidity range (Strage) | 35 to 95 % (with no condensation) |
| Insulation resistance | 20 MΩ min. (500 VDC megger) |
| Dielectric strength | 1500 VAC 50/60 Hz 1 min |
| Vibration resistance | Destruction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h |
| Malfunction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h | |
| Shock resistance | Destruction: 500 m/s2 3 times each in X, Y and Z directions |
| Malfunction: 100 m/s2 3 times each in X, Y and Z directions | |
| Degree of protection | IEC: IP64 |
| Connection method | Pre-wired models (Cable length 2 m) |
| Indicator | Operation indicator (orange), Stability indicator (green) |
| Weight | Package: Approx. 180 g |
| Accessories | Instruction manual |
| Material | ABS |
| Lens: Methacrylate resin | |
| Display: Methacrylate resin | |
| Adjustment: POM | |
| Cable: Polyvinyl chloride (PVC) |
