Autonics PRL18 8DP Proximity Switch Autonics

Description

The Autonics PRL18 8DP Proximity Switch Autonics  refers to a type of proximity sensor typically used in industrial automation for detecting the presence or absence of an object within a specific range. Here’s a detailed PRL18-8DP overview of its features and applications:

Key Features:

1. Sensing Technology: Inductive
2. Sensing Range: Typically, around 8mm (varies by specific model)
3. Output Type: PNP or NPN (depending on model)
4. Operating Voltage: Usually 10-30V DC
5. Housing Material: Often made of durable materials such as stainless steel or plastic
6. Environmental Protection: Typically rated IP67 or higher for protection against dust and water



Others

Specifications Autonics PRL18 8DP Proximity Switch Autonics

• Sensing Distance: 8mm (adjustable depending on the model)
• Response Frequency: High-speed response for rapid detection
• Operating Temperature Range: Generally -25°C to +70°C
• Indicator: LED indication for power and detection status

Wire type and power	DC 3-wire type 12-24VDC
Sensing side diameter	M18
Sensing distance	8mm
Installation	Non-flush
Standard sensing target	25×25×1mm(iron)
Response frequency	350Hz
Current specification	Current consumption: Max. 10mA
Control output	PNP Normally Open
Material	Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Ø 8 mm: SUS303),
	washer: Nikel plated Iron, sensing side: polybutylene terephthalate,
	standard cable (black): polyvinyl chloride (PVC),
	oil resistant cable (gray): oil resistant polyvinyl chloride (PVC)
Cable Standard/material	Standard cable
Protection structure	IP67(IEC standard)
Body length	Long body
Environment Ambient temperature	-25 to 70℃, storage: -30 to 80℃
Environment Ambient humidity	35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance)	Max. 10% of sensing distance
Residual voltage	Max. 1.5V
Weight	Approx. 142g(approx. 130g)



Applications:

• Industrial Automation: Used for detecting the presence or position of metal objects on production lines.
• Machine Safety: Ensures safe operation of machinery by detecting if guards or doors are closed.
• Positioning: Provides precise positioning in robotic and automated systems.
• Material Handling: Detects the position of items on conveyors and automated handling systems.

Benefits:

• Reliability: Robust design ensures reliable operation in harsh industrial environments.
• Durability: Resistant to dust and water, ensuring longevity.
• Accuracy: Provides precise and repeatable detection of metal objects.
• Ease of Installation: Simple wiring and mounting, often with built-in LED indicators for easy setup and troubleshooting.

Installation and Usage:

1. Mounting: Securely mount the sensor using the provided brackets or mounting holes.
2. Wiring: Connect the power supply and output signal wires according to the manufacturer’s wiring diagram.
3. Adjustment: Set the sensing range and sensitivity as required for your application.
4. Testing: Verify the sensor operation by checking the LED indicators and ensuring the output signal is correctly detected by the control system.

Example Manufacturers:

• Autonics
• Omron
• Keyence
• Pepperl+Fuchs
• Banner Engineering

These manufacturers provide a wide range of proximity sensors, including the PRL18-8DP, suited for various industrial applications.

For specific technical details, it’s recommended to refer to the manufacturer’s datasheet or user manual, as the exact specifications and features may vary slightly between different models and brands.
